Applications：Commonly manufactured into bearings, pump parts, components for frames, tank lids, insulators, friction strips and control discs. Primarily used in mechanical engineering, marine engineering, electrical and food and pharmaceutical applications.
Key Features:
Temperature: -20°C up to +115ºC (+180ºC short term).
Very high dimensional stability.
Excellent creep behaviour.
High mechanical strength, hardness and toughness.
Very low moisture absorption.
Good electric insulation properties.
Excellent resistance to chemicals.
Sensitive to hydrolysis.
Highly machinable.
Natural PET sheet is food approved.
|
No.
|
Category
|
Content
|
|
1
|
Characteristics
|
Easily formed, Die - cut and Punched; impact resistance
|
|
2
|
Application
|
Packaging, Vacuum therm - forming, Blister Pack
|
|
3
|
Processing Methods
|
Injection Molding
|
|
4
|
Status
|
Sheet/Plate
|
|
No.
|
Main Items
|
Values
|
Unit
|
Test Method
|
|
1
|
Density
|
1.38 - 1.57
|
g/cm³
|
ISO 1183
|
|
2
|
Shrinkage lateral flow rate
|
0.9
|
%
|
ISO 294 - 4
|
|
3
|
Shrinkage Flow
|
0.2
|
%
|
ISO 294 - 4
|
|
4
|
Water absorption:saturated 23°C
|
0.7
|
%
|
ISO 62
|
|
5
|
Water absorption saturated Balanced, 23°C, 50% RH
|
0.2
|
%
|
ISO 62
|
|
6
|
Tensile modulus 23°C
|
10500
|
MPa
|
ISO 527 - 2
|
|
7
|
Tensile stress at break, 23°C
|
150
|
MPa
|
ISO 527 - 2
|
|
8
|
Tensile strain at break, 23°C
|
2.5
|
%
|
ISO 527 - 2
|
|
9
|
Flexural modulus 23°C
|
9000
|
MPa
|
ISO 178
|
|
10
|
Flexural strength 23°C
|
240
|
MPa
|
ISO 178
|
|
11
|
Notched impact strength of simply supported beam - 30°C
|
10
|
kJ/m
|
ISO 179
|
|
12
|
Notched impact strength of simply supported beam 23°C
|
11
|
kJ/m
|
ISO 179
|
|
13
|
Simply supported beam notched impact strength - 30°C
|
45
|
kJ/m
|
ISO 179
|
|
14
|
Simply supported beam notched impact strength 23°C
|
55
|
kJ/m
|
ISO 179
|
|
15
|
Cantilever beam notched impact strength - 30°C
|
9
|
kJ/m
|
ISO 180
|
|
16
|
Cantilever beam notched impact strength 23°C
|
10
|
kJ/m
|
ISO 180
|
|
17
|
Heat distortion temperature 0.45 MPa, unannealed
|
245
|
°C
|
ISO 75 - 2/B
|
|
18
|
Heat distortion temperature 1.8 MPa, unannealed
|
220
|
°C
|
ISO 75 - 2/A
|
|
19
|
Vicat softening temperature
|
225
|
°C
|
ISO 306/B
|
|
20
|
Melting temperature DSC
|
255
|
°C
|
ISO 11346
|
|
21
|
Tracking Index
|
250
|
V
|
IEC 60112
|
|
22
|
Surface resistivity
|
1E + 14
|
Ω
|
IEC 60093
|
|
23
|
Volume resistivity
|
1E + 15
|
Ω·cm
|
IEC 60093
|
|
24
|
UL flame retardant 1.60 mm
|
V - 0
|
UL 94
|
|
|
25
|
UL flame retardant rating 3.20 mm
|
V - 0
|
UL 94
|
|
|
26
|
Glow Wire Flammability Index 2.00 mm
|
750
|
°C
|
IEC 60695 - 2 - 12
|
